| SPECIFICATIONS |
CMW/38mm/2 |
| Drill Cap. In M.S. |
38mm |
| Drill Cap.In C.I. |
40 mm |
| Tapping Cap. |
25 mm |
| Column Diameter |
108 mm |
| Ram Diameter |
72 mm |
| Spindle Traveling |
254 mm |
| Centre Of Spindle To Column Face |
254 mm |
| Taper Spindle |
M.T.4 |
| Over All Height Of Machine |
1750 MM |
| Size Of Sqare Table |
483 mm (15"*15" ) |
| Size Of Round Table |
465 mm (18" ) |
| Size Of Machine Base |
635*435 mm (25"*17" ) |
| Maximum Distance Of Spindle To Base |
1025 mm (42" ) |
| No.Of Speed Range |
8 90*2265RPM |
| V-Belt Section |
B-52 |
| Electrical Motor |
1.5/2 H.P |
| Weight Of Machine Without Motor |
300 Kgs (Approx ) |
