| SPECIFICATIONS |
CMW/25mm/3 |
| Drill Cap. In M.S. |
25 mm |
| Drill Cap.In C.I. |
32 mm |
| Tapping Cap. |
19 mm |
| Column Diameter |
90 mm |
| Ram Diameter |
72 mm |
| Spindle Traveling |
165 mm (6.5" ) |
| Centre Of Spindle To Column Face |
381 mm (15" ) |
| Taper Spindle |
M.T.4 |
| Over All Height Of Machine |
1625 mm |
| Size Of Sqare Table |
465mm (15.5"*15.5") |
| Size Of Round Table |
465 mm (18" ) |
| Size Of Machine Base |
635*435 mm (25"*17" ) |
| Maximum Distance Of Spindle To Base |
1015 mm (40" ) |
| No.Of Speed Range |
8 96*3200RPM |
| V-Belt Section |
B-59 |
| Electrical Motor |
1.5/2 H.P |
| Weight Of Machine Without Motor |
230 Kgs (Approx ) |
